  • Window with installed Garage Door Rain Diverter to prevent water dripping and fix leaking windows
  • Extended width garage door rain diverter installed above blue-framed windows on gray wooden siding to prevent water dripping and fix leaking windows
  • DOORBRIM | rain diverter installation kit with sealant, screws, and washers
  • Logo with American flag surrounded by a gold ribbon.
1 10

The Rain Diverter Store

Garage door rain guard| Front Gutter Routes Water Away from Overhead Doors | Prevents Dripping | DOORBRIM | EXTENDED WIDTH 98-136 Inch Wide

Garage door rain guard| Front Gutter Routes Water Away from Overhead Doors | Prevents Dripping | DOORBRIM | EXTENDED WIDTH 98-136 Inch Wide

$679.00 USD
$679.00 USD
Sale Sold out
Shipping calculated at checkout.
Color
Size
ADD: Installation Kit

The garage door rain guard from DOORBRIM is designed to direct water away from overhead garage doors, preventing leaks, dripping, and water accumulation on floors. It is molded from 1/4 inch thick, durable ABS plastic, offering strong resistance to weather and impact. This garage door rain guard mounts surface-level using mechanical fasteners through predrilled holes spaced 12 inches apart and can be sealed with included silicone caulk for a watertight installation. Custom widths from 98 to 136 inches are available, with extended widths utilizing optional structural brackets to achieve continuous coverage. The garage door rain guard is offered in factory UV-protected colors including Almond (Off White), Lt Gray, and Lt Beige. All sizes and colors are proudly made in the USA, in stock, and ready to ship next-day. The extended width garage door rain guard requires the use of structural brackets for widths greater than 54 inches. These brackets ensure proper support and prevent sagging or damage. Installation is straightforward when using the complete kit, which includes color-matched fasteners tailored for concrete, stucco, brick, or wood siding, along with silicone caulk and a carbide drill bit. The garage door rain guard can be installed on various building surfaces, making it suitable for different garage structures. Use cases for this rain guard include residential garages prone to water intrusion, commercial garages needing to prevent water runoff, and any overhead garage door setup requiring a water diversion solution. A garage door rain guard is ideal for homeowners on a budget seeking a reliable, long-lasting water management solution, as well as contractors installing custom-sized rain diverters for multiple properties. Included in the box are the ABS rain guard, predrilled mounting holes, fasteners, silicone sealant, and a carbide drill bit. Structural brackets are sold separately and are required for widths over 54 inches. The garage door rain guard does not include additional fasteners but an optional installaion kit is offered.. Care instructions involve periodic cleaning with mild soap and water to maintain appearance. The rain guard is designed for permanent outdoor installation and does not require special maintenance beyond routine cleaning. Warranty details are not specified but is consistent with industry standards for durable plastic outdoor components.

Country of Origin

Proudly Made in USA, Splice Brackets are Imported.

Materials

DOORBRIM rain diverters are molded from strong 1/4-inch ABS plastic material. The finish product is durable and able to withstand high winds and harsh environments.

Dimensions

All products are 7 1/2" High and PROJECTION is 7 1/2" from the Wall. STANDARD width is 52" inside to inside. OVERALL width is 54 1/2" including the mounting flange on each side. THICKNESS begins with 1/4" raw material. FINISH THICKNESS varies due to the molding process.

Unlimited custom widths are achieved with the use of intermediate splice brackets

Availability & Shipping

All color and width variations are in stock and ship SAME or NEXT DAY.

Tools Required

  • Step ladder
  • 4’ level
  • Hammer drill
  • 3/8” socket and ratchet
  • Pencil
  • Caulking gun

Installation Instructions

Rain diverters can be mounted on concrete, stucco, masonry, brick, wood, vinyl siding or metal surfaces.

Draw a level line above door or window. Using your rain diverter as a template, mark holes, then drill out the holes. Apply caulking to outer flange and screw the rain diverter the to wall with a ratchet and socket. CAUTION: Do not over tighten.

If your rain diverter has a splice bracket, install the bracket first leaving a little play. Caulk the rain diverter flanges and insert into the bracket. Tighten all fasteners.

Warranty

DOORBRIM rain diverters are warranted for 1 year against manufacturer defects. Does not include cracking due to over tightening.

Returns

Please be aware that EXTENDED AND SHORTER width rain diverters use a center structural bracket to achieve various widths. Be sure to verify there are no conflicts with this bracket. Custom fabricated sizes using a splice bracket (EXTENDED AND SHORTER width specifically) are NOT RETURNABLE. View our RETURN POLICY here: https://doorhood.com › pages › return-policy

View full details

FAQs

What material is a DOORBRIM rain diverter or drip edge made from and can they be painted?
DOORBRIM rain diverters are molded from strong 1/4-inch ABS plastic material. The finish product is durable and able to withstand high winds and harsh environments. DOORBRIM rain guards come finished with a two-part epoxy containing a UV inhibitor. This factory finish will also serve as an excellent primer. You can repaint with an ordinary can of spray paint to create a beautiful custom finish.

How are rain diverters or rain guards mounted?
Rain diverters are surface mounted above doors, windows or outdoor electrical equipment with optional color matched mechanical fasteners through predrilled holes. Installation above the top trim header is advised to stop any leaks originating from behind the header. The standard width of the rain diverter or rain guard is 52 inches. to accommodate large windows, double doors and overhead garage doors etc.

Are custom sizes available for the rain diverter?
Yes, custom width sizes are available with the use of intermediate structural splice brackets to accommodate large windows, double doors, overhead garage doors, electric services panels or any other outdoor electrical equipment exposed to inclement weather. All products project 7 1/2 inches from the structure. Factory UV protected colors are available in ALMOND (off-white) BEIGE and GRAY.

What is included in the complete installation kit?
The complete installation kit includes 100% silicone clear caulking, matching fasteners for wood, concrete, stucco, brick and siding. Also included is a carbide drill bit for the fasteners.

What makes DOORBRIM rain hoods or drip edges so effective?
There's a small gutter in the front that funnel rain water to the two sides then out and away from your structure. In addition to shield in your door window or electrical equipment, this prevents leaks and drips.

What other names are used to refer to Doorbrim rain diverters?
DOORBRIM rain diverters are also referred to as drip edges, rain guards, rain hoods, rain deflectors, rain drip guards. They are also referred to as weatherproof covers or hoods for all unprotected electrical devices?

What are common uses for DOORBRIM rain diverters?
The predominant use of DOORBRIM rain diverters is to stop leaks when mounted over or above all types of doors, including but not limited to exterior doors, garage doors, overhead doors, roll up doors, side doors, roof access doors, entry doors, French doors, double doors, shed doors, pet doors, RV and mobile home doors. Other common uses include protecting windows and all exterior electrical equipment such as electric service panels, EV chargers, pool equipment, tell entry panels, outdoor speakers and mailboxes.
